| Edge thickness | 0.4-3mm |
| Tape thickness | 12-62mm |
| Panel thickness | 10-60mm |
| Heating power | 2.0kw |
| Preheating power | 350w |
| Conveyor belt motor power | 2.2kw |
| Pre-milling motor power | ----- |
| Glue shaft motor power | 0.75kw |
| End cutting motor power | 0.37 kw*2 @12000rpm |
| Rough trimming motor power | 0.75 kw*2 @ 12000rpm |
| Fine trimming motor power | 0.75 kw*2 @ 12000rpm |
| Buffing motor power | 0.37 kw*2 @ 1350rpm |
| Electrical lifting beam motor power | ----- |
| Conveyor belt speed | 12-20m/min |
| Air pressure | 0.7Mpa |
| Total motor power | 10.5kw |
| Dimension | 4600*1000*1600mm |
| Net weight | 1700kgs |
